RAK Close-Coupled Toilet Suite Boxed Rim S-Trap Only - Washington White

Name: RAK Close-Coupled Toilet Suite Boxed Rim S-Trap Only - Washington White
Brand: RAK Ceramics
SKU: FN-060130W
Price: 768.00 AUD
Availability: InStock

SKU: FN-060130W

Product Overview

Feature	Essential	Advantage	Ultimate
Extended Warranty	+5 Years	+10 Years	+15 Years
Transit Damage Coverage	up to $500	up to $3,000	up to $10,000
On-Site Support	--	--	3 Years
Price	$15	$10	$5

Specifications

Features

Close-Coupled Toilet Suite

This close-coupled toilet suite features a box rim design with high-quality Geberit flush mechanism, paired with a UF soft close seat for quiet operation. Finished in alpine white with stainless steel hinges, it offers reliable performance and a clean, modern look for any bathroom.

Close-Coupled Box Rim Dual Flush 4.5/3L WELS 4 Star S-Trap 240mm Alpine White

Material & Finish

Premium Ceramic Construction with Stainless Steel Hinges

Crafted from high-quality vitreous china for durability and long-lasting performance. The alpine white finish provides a clean, bright look that complements any bathroom decor.

Stainless steel hinges offer enhanced corrosion resistance and stability, ensuring the seat remains secure and functional for years to come.

Close-Coupled Toilet ceramic construction alpine white

Flushing System

Box Rim Design with Geberit Flush Mechanism

The box rim design ensures efficient water distribution and a powerful flush, keeping the bowl clean with every use. The high-quality Geberit flush mechanism delivers reliable performance and quiet operation.

The dual flush system provides flexibility between full and half flush, helping to save water without compromising on flushing power.

Close-Coupled Toilet box rim Geberit flush mechanism

TOILET SUITE

WELS Certified Water Saving Technology

Engineered for high performance and environmental sustainability, this system complies with strict water efficiency standards to reduce water consumption without sacrificing flush power.

WELS Registration No: L01764
WELS Star Rating: 4 Star
Flush Volume: 4.5L (Full Flush) / 3L (Half Flush)
Average Flush: 3.4L

Technical & Installation

S-Trap 240mm with Flexible Water Inlet

Designed with an S-trap configuration with a 240mm set-out, making it suitable for standard bathroom plumbing setups. The water inlet position can be either left or right bottom inlet, providing installation flexibility.

The model code for this S-trap version is 060130W, ensuring you receive the correct configuration for your installation needs.

Close-Coupled Toilet S-trap 240mm installation

Note:
A measurement deviation of ±5mm is regarded as a common and acceptable variation in ceramic products.
Model: 060130W (S-TRAP)
Watermark Approved (Licence No: WMKA01985)
Please consult your licensed plumber or hydraulic consultant prior to purchase and installation.
For full warranty details, please refer to the warranty information provided with the product or contact the manufacturer.

Product Information

MODEL
Main Product Code	060130W (S-TRAP)
MATERIAL & FINISH
Material	Ceramic, Stainless steel hinges
Colour	Alpine White
TECHNICAL INFORMATION
Flushing	Box Rim, High quality, Geberit flush mechanism
Toilet Seat	UF soft close seat
Hinge Cover	Thickness: 7.65mm, Diameter: 50.4mm
Trap	S-Trap , 240mm
Water Inlet Position	Left or right bottom inlet
CERTIFICATION
WATERMARK	Approved
WATERMARK Licence No	WMKA01985
WELS	Approved
WELS Licence No	0144
WELS Registration No	L01764
WELS Star Rating	4 Star, 4.5L/full, 3L/half, 3.4L average flush
PACKAGE CONTENTS
Main Product	1 x Close-Coupled Toilet
Accessories	Includes concealed floor fixing screws
WARRANTY（Residential）
Vitreous China	5 years replacement parts or product, 1 year labour
Geberit Cisterns（Valves）	3 Years replacement parts or product, 1 year labour
Seats, Accessories & Spare Parts	1 Year replacement parts or product

WARRANTY（Commercial）
Vitreous China	3 years replacement parts or product, 1 year labour
Geberit Cisterns（Valves）	3 Years replacement parts or product, 1 year labour
Seats, Accessories & Spare Parts	1 Year replacement parts or product

Supplier's Gallery

Dimensions

Instruction

Specification Sheet

Complete product specifications and dimensions for RAK Washington close‑coupled toilet suite.

📄

RAK Washington Toilet Specification Sheet (PDF)

Features, dimensions, trap types and installation details.

Download PDF

Installation should be carried out by a licensed plumber where required.
